LUMii XLED Controller
The LUMii XLED Controller is designed to control the LUMii XLEDv6 680w LED fixture, but can control any LED fixture which accepts a 0-10V control signal. When connected to an RJ12 port (or by wired connection to push-in terminals), it will schedule a desired daily photoperiod, control the light intensity (dimming) from 0% to 100%, and set the length of sunrise and sunset ramping. With its single channel, it will control a linked array of up to 25 LUMii XLEDv6 680w LED fixtures. The controller uses a very simple five-button control interface with an LED display. It has an integral wall mounting/hanging tab and is powered from mains electricity via an adaptor plug (supplied).
Key selling points:
- Controls any LED fixture accepting a 0-10V signal
- Sets photoperiod, dimming, sunrise and sunset ramping.
- Simple 5-button controls
- Main adaptor plug supplied
Technical Specifications:
- Number of Channels: 1
- Signal Type: 0 – 10 V
- Maximum Number of Fixtures Controlled: 25
- 10 V Output Control: 0 – 10 V ± 0.1 V
- Adaptor AC Input Power: 120 – 240 V
- Controller DC Input Power: 12 V, 1.0A
- Operating temperature: 0°C - 35°C (32°F - 95°F)
- Operating Humidity: 80% RH Maximum, non-condensing
- IP Rating: IP20
