Ceramic Metal Halide (CMH) Digital Ballast Kit 630W DE
Ceramic Metal Halide is the latest in HID lighting technology! It offers low frequency, square wave, soft start technology with dimmable functionality.
This CMH Grow Light Kit includes:
630W CMH Digital Ballast
630W DE CMH Lamp – Color: 3200K CRI: ≥85
IR Remote Control (one remote can operate more than one ballast).
For more info on CMH Technology visit:
Next-generation smart digital control the light source ignition technology, ignition distance up to 20 meters.
Using high-performance special lighting CPU control technology, intelligent detection light source management adjust the best luminous flux and electricity consumption in real time.
Next-generation smart digital ignition energy control technology, it can prevent the damage of the light source and extend the lamps life.
Next-generation smart digital lamp startup control technology, high-precision digital control lamp startup current, it can control the light attenuation and working life of the lamp furthest.
Smart digital lamp protection technology with high stability of lamp current control, dynamic lamp power control, smart lamp auto-adapt light attenuation control allowing the lamp to work for up to 5 years.
High reliability digital driver circuit. It offers smart, high sensitivity anti-thunder, open circuit, short circuit, over-current, over-voltage and over-temperature protection technology.
Efficiency: > 91% , high performance APFC circuit, power factor up to 0.99, THD<6%, efficient green energy conservation and environmental protection.
Using the most sophisticated R&D and production process, with high outdoor quality standards.
Working light source: Ceramic Metal Halide (CMH), High Pressure Sodium (HPS), Quartz Metal Halide (QMH).
Multi-voltage input (120V / 208V / 240V).
Smart infrared remote control dimmer - remembers when to power off and can control the output power: 700W, 630W, 400W, 300W, 0W (power off).
With 0-10V standard interface input, convenient access control systems to control, adjustable power range: 300W-700W.( When 1000W On )
1. Product Specifications:
AC input voltage
AC inrush current（Max)
Cold start 70A/230VAC
5.58A@120VAC, 3.22A@208VAC, 2.79A@240VAC
Light Decay Control attenuation
Ballast power dissipation
Scalable communication interface
0～10V、Infrared remote control interface
Open or short circuit protection
Automatic shutdown, troubleshooting on again to resume work
Hot start protection
If ignition fails it will try to ignite 3 times in a minute. If ignition is still unsuccessful it will try ignite a further 3 times for the next 10 minutes. If ignition is still unsuccessful it will automatically shutdown.
Set limit temperature, lower power protection
L-N:5KV; L-PE:5KV; N-PE:5KV
3.Products comply with CE / CCC / UL standards:
4.Environmental noise standards: GB/T14623:Urban regional environmental noise standards
